Customizing openHAB – Android application for IoT project

openHAB is a widely accepted open source automation software for home, office, etc. It written in Java and is lightweight and can set up in Linux, OS X or Windows. You can run openHAB on RaspberryPi. openHAB project also includes mobile client applications for both iOS and Android. Since these applications are part of the open source project the UI of the application is not promising. But we can easily make the UI of the application better without much effort.

Customizing openHAB Android application

In this document, I will give a brief idea about, how to begin with changing the UI of the openHAB android application. I will explain how did we modify the switch and slider components in the application with our own design. You can do the same for all the layouts in the application and have the application a new look.

Changing the icons

We can easily add new icons to the application by replacing or adding the images to “/opt/openhab/webapps/images/”, make sure that the new names are used in the sitemaps “/opt/openhab/configurations/sitemaps/*.sitemap”

Changing the layout of controls

To change the UI of the openHAB application we need to update the layout files. Select layout file of the control and do the update as needed like changing the background color, style of the views, the appearance of the views, properties of the views etc. Make sure that you are not removing any views from these layouts. If we remove views from these layouts unexpected error could occur. Just focus on the appearance.
Customizing android views Switch and Slider

We also need to customize the Switch and Slider views in the application.

New theme

The application theme is also changed. We added a new theme in ..res/values/themes.xml file.

For our application we changed the layout of the Switch component is modified from

to

the slider component has changed from

to

The source changes are given below.

…res/layout/openhabwidgetlist_switchitem.xml(original)

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="wrap_content"
    android:background="?android:activatedBackgroundIndicator"
    android:paddingLeft="@dimen/widgetlist_item_left_margin"
    android:paddingRight="@dimen/widgetlist_item_right_margin">

    <include
        android:id="@+id/switchleftlayout"
        layout="@layout/openhabwidgetlist_icontext" />

    <android.support.v7.widget.SwitchCompat
        android:id="@+id/switchswitch"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_alignParentRight="true"
        android:layout_centerVertical="true"
        android:layout_marginRight="3dip"
        android:focusable="false"
        android:focusableInTouchMode="false" />

    <LinearLayout
        android:id="@+id/listdivider"
        android:layout_width="fill_parent"
        android:layout_height="1dip"
        android:layout_below="@+id/switchleftlayout"
        android:layout_marginLeft="@dimen/widgetlist_divider_left_margin"
        android:layout_marginRight="@dimen/widgetlist_divider_right_margin"
        android:background="?android:attr/listDivider"
        android:orientation="horizontal" />
</RelativeLayout>

…res/layout/openhabwidgetlist_switchitem.xml(modified)

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
   android:layout_width="fill_parent"
   android:layout_height="?attr/widgetListItemHeight"
   android:paddingLeft="@dimen/widgetlist_item_left_margin"
   android:paddingRight="@dimen/widgetlist_item_right_margin"
   android:background="?attr/widgetListItemBackground">
   <org.openhab.habdroid.util.MySmartImageView
        android:layout_width="56dip"
        android:layout_height="56dip"
        android:id="@+id/widgetimage"
        android:layout_centerVertical="true"
        android:maxWidth="56dip"
        android:minWidth="56dip"
        android:maxHeight="56dip"
        android:minHeight="56dip"
        android:alpha=".50"
        />

    <TextView
        android:layout_marginLeft="16dp"
        android:layout_marginStart="16dp"
        android:id="@+id/widgetlabel"
        android:ellipsize="end"
        android:maxLines="1"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_toRightOf="@id/widgetimage"
        android:layout_centerVertical="true"
        android:textAppearance="?android:attr/textAppearanceLarge" />


    <Switch
        android:id="@+id/switchswitch"
        android:layout_width="90dp"
        android:layout_height="45dp"
        android:layout_alignParentRight="true"
        android:layout_alignParentEnd="true"
        android:layout_centerVertical="true"
        android:thumb="@drawable/switch_selector"
        android:track="@drawable/switch_track"
        android:checked="true"
        android:textOn="ON"
        android:textOff="OFF"
        android:switchTextAppearance="@style/SwitchTextAppearance"
        android:showText="true"
        />

    <LinearLayout
        android:id="@+id/listdivider"
        android:layout_width="fill_parent"
        android:layout_height="1dp"
        android:layout_marginLeft="@dimen/widgetlist_divider_left_margin"
        android:layout_marginRight="@dimen/widgetlist_divider_right_margin"
        android:background="?attr/widgetListItemDivider"
        android:orientation="horizontal"
        android:layout_alignParentBottom="true"/>
</RelativeLayout>

…res/layout/openhabwidgetlist_slideritem.xml(original)

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="wrap_content"
    android:paddingLeft="@dimen/widgetlist_item_left_margin"
    android:paddingRight="@dimen/widgetlist_item_right_margin"
    android:background="?android:activatedBackgroundIndicator">
    <include
        android:id="@+id/sliderleftlayout"
        layout="@layout/openhabwidgetlist_icontext" />
    <SeekBar
        android:id="@+id/sliderseekbar"
        android:layout_width="130dip"
        android:layout_height="wrap_content"
        android:layout_alignParentRight="true"
        android:layout_centerVertical="true"
        android:max="100" />
    <LinearLayout
        android:id="@+id/listdivider"
        android:layout_width="fill_parent"
        android:layout_height="1dip"
        android:background="?android:attr/listDivider"
        android:orientation="horizontal"
        android:layout_below="@+id/sliderleftlayout"
        android:layout_marginLeft="@dimen/widgetlist_divider_left_margin"
        android:layout_marginRight="@dimen/widgetlist_divider_right_margin" />
</RelativeLayout>

…res/layout/openhabwidgetlist_slideritem.xml(modified)

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:id="@+id/wrapper"
    android:layout_width="fill_parent"
    android:layout_height="?attr/widgetListItemHeight"
    android:paddingLeft="@dimen/widgetlist_item_left_margin"
    android:paddingRight="@dimen/widgetlist_item_right_margin"
    android:background="?attr/widgetListItemBackground">
    <RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
        android:id="@+id/icontextlayout"
        android:layout_width="wrap_content"
        android:layout_height="match_parent"
        android:layout_alignParentLeft="true">

        <org.openhab.habdroid.util.MySmartImageView
            android:layout_width="56dip"
            android:layout_height="56dip"
            android:id="@+id/widgetimage"
            android:layout_centerVertical="true"
            android:maxWidth="56dip"
            android:minWidth="56dip"
            android:maxHeight="56dip"
            android:minHeight="56dip"
            android:alpha=".50"
            />

        <TextView
            android:id="@+id/widgetlabel"
            android:layout_marginLeft="16dp"
            android:layout_marginStart="16dp"
            android:layout_alignTop="@id/widgetimage"
            android:layout_toRightOf="@id/widgetimage"
            android:layout_toEndOf="@id/widgetimage"
            android:ellipsize="end"
            android:maxLines="1"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:textAppearance="?android:attr/textAppearanceLarge" />

        <TextView
            android:id="@+id/widgetvalue"
            android:layout_alignTop="@id/widgetimage"
            android:layout_alignParentEnd="true"
            android:layout_alignParentRight="true"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:textAppearance="?android:attr/textAppearanceLarge" />

        <SeekBar
            android:id="@+id/sliderseekbar"
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:layout_alignLeft="@id/widgetlabel"
            android:layout_alignBottom="@id/widgetimage"
            android:layout_marginStart="-16dp"
            android:layout_marginLeft="-16dp"
            android:layout_marginRight="-16dp"
            android:layout_marginEnd="-16dp"
            android:progressDrawable="@drawable/seekbar_progress_drawable"
            android:thumbOffset="0dp"
            android:max="100"
            android:thumb="@drawable/seekbar_thumb"/>
    </RelativeLayout>

    <LinearLayout
        android:id="@+id/listdivider"
        android:layout_width="fill_parent"
        android:layout_height="1dp"
        android:background="?attr/widgetListItemDivider"
        android:orientation="horizontal"
        android:layout_alignParentBottom="true"
        android:layout_marginLeft="@dimen/widgetlist_divider_left_margin"
        android:layout_marginRight="@dimen/widgetlist_divider_right_margin" />
</RelativeLayout>

…res/drawable/seekbar_background.xml(added)

<?xml version="1.0" encoding="utf-8"?>
<shape xmlns:android="http://schemas.android.com/apk/res/android"
    android:shape="line">
    <stroke android:width="2dp" android:color="@color/seekBarTrack"/>
</shape>

…res/drawable/seekbar_progress.xml(added)

<?xml version="1.0" encoding="utf-8"?>
<shape xmlns:android="http://schemas.android.com/apk/res/android"
    android:shape="line">
    <stroke android:width="2dp" android:color="@color/seekBarTrackPrimaryProgress"/>
</shape>

…res/drawable/seekbar_progress_drawable.xml(aaded)

<?xml version="1.0" encoding="utf-8"?>
<layer-list xmlns:android="http://schemas.android.com/apk/res/android" >
    <item android:id="@android:id/background"
        android:drawable="@drawable/seekbar_background"/>
    <item android:id="@android:id/secondaryProgress">
        <clip
            android:drawable="@drawable/seekbar_secondary_progress" />
    </item>
    <item android:id="@android:id/progress">
        <clip
            android:drawable="@drawable/seekbar_progress"/>
    </item>
</layer-list>

…res/drawable/seekbar_progress_drawable_highlighed.xml(added)

<?xml version="1.0" encoding="utf-8"?>
<layer-list xmlns:android="http://schemas.android.com/apk/res/android" >
    <item android:id="@android:id/background"
        android:drawable="@drawable/seekbar_background"/>
    <item android:id="@android:id/secondaryProgress">
        <clip
            android:drawable="@drawable/seekbar_secondary_progress" />
    </item>
    <item android:id="@android:id/progress">
        <clip
            android:drawable="@drawable/seekbar_progress_highlighted"/>
    </item>
</layer-list>

…res/drawable/seekbar_progress_highlighted.xml(added)

<?xml version="1.0" encoding="utf-8"?>
<shape xmlns:android="http://schemas.android.com/apk/res/android"
    android:shape="line">
    <stroke android:width="2dp" android:color="@color/seekBarTrackPrimaryProgressHighlighted"/>
</shape>

…res/drawable/seekbar_secondary_progress.xml(added)

<?xml version="1.0" encoding="utf-8"?>
<shape xmlns:android="http://schemas.android.com/apk/res/android"
    android:shape="line">
    <stroke android:width="2dp" android:color="@color/seekBarTrackSecondaryProgress"/>
</shape>

…res/drawable/seekbar_thumb.xml(added)

<?xml version="1.0" encoding="utf-8"?>
<selector xmlns:android="http://schemas.android.com/apk/res/android">
    <item android:state_pressed="true">
        <shape xmlns:android="http://schemas.android.com/apk/res/android"
            android:shape="oval">
            <size android:height="24dp" android:width="24dp"/>
            <solid android:color="@color/seekBarThumb" />
            <stroke android:color="@color/seekBarThumbTransparent" android:width="4dp"/>
        </shape>
    </item>
    <item>
        <shape xmlns:android="http://schemas.android.com/apk/res/android"
            android:shape="oval">
            <size android:height="24dp" android:width="24dp"/>
            <solid android:color="@color/seekBarThumb" />
        </shape>
    </item>
</selector>

…res/drawable/seekbar_thumb_highlighted.xml(added)

<?xml version="1.0" encoding="utf-8"?>
<selector xmlns:android="http://schemas.android.com/apk/res/android">
    <item android:state_pressed="true">
        <shape xmlns:android="http://schemas.android.com/apk/res/android"
            android:shape="oval">
            <size android:height="24dp" android:width="24dp"/>
            <solid android:color="@color/seekBarThumbHighlighted" />
            <stroke android:color="@color/seekBarThumbTransparent" android:width="4dp"/>
        </shape>
    </item>
    <item>
        <shape xmlns:android="http://schemas.android.com/apk/res/android"
            android:shape="oval">
            <size android:height="24dp" android:width="24dp"/>
            <solid android:color="@color/seekBarThumbHighlighted" />
        </shape>
    </item>
</selector>

…res/drawable/switch_selector.xml(added)

<?xml version="1.0" encoding="utf-8"?>
<selector xmlns:android="http://schemas.android.com/apk/res/android" >
    <item android:state_checked="false">
        <shape
            android:shape="oval"
            android:visible="true"
            android:dither="true"
            android:useLevel="false">
            <stroke android:color="@android:color/transparent"
                android:width="4dp"/>
            <solid  android:color="@color/colorSwitchOff"/>
            <size
                android:width="45dp"
                android:height="45dp" />
        </shape>
    </item>
    <item android:state_checked="true">
        <shape
            android:shape="oval"
            android:visible="true"
            android:dither="true"
            android:useLevel="false">
            <stroke android:color="@android:color/transparent"
                android:width="4dp"/>
            <solid  android:color="@color/colorSwitchOn"/>
            <size
                android:width="45dp"
                android:height="45dp" />
        </shape>
    </item>
</selector>

…res/drawable/switch_track.xml(added)

<?xml version="1.0" encoding="utf-8"?>
<selector xmlns:android="http://schemas.android.com/apk/res/android">
    <item android:state_checked="false">
        <shape xmlns:android="http://schemas.android.com/apk/res/android"
            android:shape="rectangle"
            android:visible="true"
            android:dither="true"
            android:useLevel="false">
            <corners android:radius="25dp"/>
            <solid android:color="@color/colorSwitchTrack"/>
            <stroke android:color="@color/colorSwitchTrackBorder"
                android:width="1px"/>
            <size
                android:width="90dp"
                android:height="45dp" />
        </shape>
    </item>
    <item android:state_checked="true">
        <shape xmlns:android="http://schemas.android.com/apk/res/android"
            android:shape="rectangle"
            android:visible="true"
            android:dither="true"
            android:useLevel="false">
            <corners android:radius="25dp"/>
            <solid android:color="@color/colorSwitchTrack"/>
            <stroke android:color="@color/colorSwitchTrackBorder"
                android:width="1px"/>
            <size
                android:width="90dp"
                android:height="45dp" />
        </shape>
    </item>
</selector>

…res/values/colors.xml(modified)

.....
<color name="windowBackground">#000000</color>
<color name="colorActionBar">#D9D9D9</color>
<color name="colorSwitchTrack">#804C5266</color>
<color name="colorSwitchTrackBorder">#804C5266</color>
<color name="colorSwitchOn">#E3E3E5</color>
<color name="colorSwitchOff">#E3E3E5</color>
<color name="colorSwitchTextOff">#000000</color>
<color name="colorSwitchTextOn">#4d536b</color>
<color name="seekBarTrack">#80ffffff</color>
<color name="seekBarTrackSecondaryProgress">#80ffffff</color>
<color name="seekBarTrackPrimaryProgress">@android:color/transparent</color>
<color name="seekBarThumb">#80ffffff</color>
<color name="seekBarThumbTransparent">#40ffffff</color>
<color name="seekBarTrackPrimaryProgressHighlighted">#ffffff</color>
<color name="seekBarThumbHighlighted">#ffffff</color>
<color name="widgetListDividerColor">#000000</color>
<color name="textColor">#80ffffff</color>
<color name="widgetBackground">#000000</color>
.....

..res/values/themes.xml(modified)

....
<style name="HABDroid.Custom" parent="@style/Theme.AppCompat">
    <item name="android:windowBackground">@color/windowBackground</item>
    <item name="customMicIcon">@android:drawable/ic_btn_speak_now</item>
    <item name="widgetListItemDivider">@color/widgetListDividerColor</item>
    <item name="widgetListItemHeight">84dp</item>
    <item name="widgetListItemBackground">@color/widgetBackground</item>
    <item name="frameWidgetDividerBackground">@color/black</item>

    <item name="colorPrimary">@color/colorPrimary</item>
    <item name="colorAccent">@color/colorAccent</item>
    <item name="colorPrimaryDark">@color/colorPrimary_Dark</item>

    <item name="windowNoTitle">true</item>
    <item name="windowActionBar">false</item>
    <item name="windowActionBarOverlay">false</item>
    <item name="themedActionBarBackground">@drawable/action_bar</item>
    <item name="themedDrawerBackground">@color/lightBackground</item>
    <item name="themedHeaderTextColor">@color/colorPrimary</item>
    <item name="android:textColor">@color/textColor</item>
</style>
....

..res/values/attrs.xml(modified)

....
<attr name="widgetListItemBackground" format="color"/>
<attr name="widgetListItemHeight" format="dimension"/>
....

In the openHab server /opt/openhab/configurations/sitemaps/*.sitemap is modified to

sitemap MySmartHome label="My Smart Home"{
    Frame {
        Switch item=g001 label="Master" icon="smart_switch"
        Switch item=g002 label="onoff group" icon="smart_switch"
        Slider item=g003 label="dimming group" icon="smart_fan"
    }
}

The following icons are added to the openHAB server to the location “/otp/openhab/webapps/images”

link1, link2
